Chip Ultracapacitor

The First Low ESR, Slim-profile, Reflowable Ultracapacitor

Odoo - Sample 1 for three columns

key FEATURES and benefits

Highest energy density board mountable ultracapacitor
Wide operating language
Pick-and-place compatible
Pb-free reflow compliant
Surface mount design
Sealed ceramic package
Long lifetime
RoHS Compliant
Small footprint, thin profile

preliminary specifications


 Form Factor: 8 x 11 x 2.3 (mm)

Typical Capacitance at 25°C
300 mF *
Typical Capacitance at 85°C
305 mF*
Operating Voltage
2.1 V
Typical ESR at 25°C
160 mΩ*
Typical ESR at 85°C
85 mΩ*
Mass
0.57g*
variation
*+-20% Variation
Odoo • Image and Text

DOWNLOAD 8x11 dataSHEET

 Form Factor: 9 x 22 x 1.9 (mm)

Typical Capacitance at 25°C
500 mF *
Typical Capacitance at 85°C
505 mF*
Operating Voltage
2.1 V
Typical ESR at 25°C
50 mΩ*
Typical ESR at 85°C
45 mΩ*
Mass
1.2g*
variation
*+-20% Variation
Odoo • Image and Text

DOWNLOAD 9x22 dataSHEET

applications

Power loss protection
Wireless sensors
Energy Harvesting
Pulsed power
Iot
